Foodgrade Stainless steel AISI316 rotor, casted in one piece Stainless steel slide with aluminum bearing housings Suited for pressure differentials up to approx. 0.4 bar No adjusting needed afterwards No drive dismount needed when cleaning
Many of you know this problem. Again and again your rotary valve has to be fully dismounted and cleaned, because a new medium has to be processed and you want to prevent contamination of your product flow. To avoid this annoying and often costly task, VDL has developed a new, quick-disassembly version of its well-known HT-S rotary valve.
This HT-S Easy Clean valve combines the qualities of the HT-S with a high level of efficiency in cleaning because the rotor can be removed and repositioned in an easy manner, without tools.
Dosing valve
Drop-through valve for use as an air lock in high vacuum
systems and dosing valve under silos and bunkers.
Transport of powders and granulates
Suitable for the transport of powders and granulates with medium pressure differences.
Valve for e.g. nutrients or pigment powders
This rotary valve can also be used for pigment powders, where it is important that after each batch or color change, the entire installation, including the valve, is easy to clean. This way, no color can remain that could lead to mixing with the next batch.
| Size | : DN250 (DN350 follows) |
| Rotor volume | : 7 (20 liter follows) |
| House | : In- and outside fully nickel plated, foodgrade |
| Rotor | : Stainless steel AISI316 rotor, casted in one piece |
| Bearing | : Stainless steel slide with aluminum bearing housings |
| Pressure difference | : 0.4 bar |
